| Working Load: | 3T | Suitable Rope: | 16-20mm |
|---|---|---|---|
| Application: | Tightening Wire Rope | Weight: | 5kg |
| Product Name: | Bolt Type Kitto Clamp 3T for Gripping Steel Wire Rope 16-20mm | Item: | Kitto Clamp |
| Vurgulamak: | wire rope grips,come along clamp |
||
Bolt Type Kitto Clamp Tightening Wire Rope 3 Ton Working Load
Applicaction
Wire rope bolt type, is used for steel core aluminum stranded wire;Steel strand.Instruments of wire rope or wire clamp and tighten.
1. Bolt type,easily application.
2. Strong tension stress.
3. Groove type structure,no damage to the conductor.
Technical Data
| Item Number | Load (T) | Wire Rope(mm) | Dimension(mm) | Weight(kg) | Package | |||
| A | B | C | L | Pkg/pcs | ||||
| T6-10 | 1 | 6-10 | 65 | 32.2 | 124.5 | 71.0 | 0.97 | 10 |
| T12-14 | 2 | 12-14 | 80 | 40.0 | 162.0 | 89.5 | 2.24 | 6 |
| T16-20 | 3 | 16-20 | 96 | 44.5 | 217.0 | 134.0 | 5.00 | 6 |
| T22-26 | 5 | 22-26 | 96 | 49.0 | 218.0 | 141.0 | 6.70 | 4 |
| T28-32 | 6 | 28-32 | 96 | 49.0 | 223.0 | 141.0 | 7.54 | 4 |
Each Parts
